Manual Single Door Oxygen Cylinder Storage Cabinets 14 GA Steel Roof Material

Basic Information
Place of Origin: Ningbo
Brand Name: Brynick
Certification: Meets OSHA 1910. 110standards
Model Number: BN8010601
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Carton Flat Packing and Pallet
Delivery Time: 5-30 days upon order quantity
Payment Terms: T/T, Western Union
Supply Ability: 2500 sets per 25 days
Detail Information
Name: Storage Locker Height: 65"
Chain: 1 Roof Material: 14 GA Steel
Door Type: Manual With Magnetic Capacity: 9

Product Description

Single Door Expanded Metal Cabinet for Storage of 9 vertical up to 59 ¾ Inch High Gas Cylinder


Application

Vertical storage lockers Accommodate 9 vertical cylinders up to 200 Lbs. or 59¾ inch tall



Features

  • Solid 14 – Gauge Steel Top and Bottom
  • Door Handle for Easy Opening
  • Magnetic Door Catches for Completely Close
  • Padlock Ready Hasp for Security
  • Expanded Metal Door and Sides
  • Adjustable Chains for Securing Vertical Cylinders, Adjust in 1" Increments
  • Warning Flammable Sign on Cabinet Door
  • Pre – Drilled Lagging Holes for Floor Mounting
  • Meets OSHA 1910 Standard



Description

Made of heavy-gauge 14 GA expanded metal, 1 ½” x 1/8” angle steel frame, 14 GA steel top and bottom. Heavy-duty butt hinges and padlock hasp keeps contents secure for safety. Magnetic catch keeps door shut when not locked. Predrilled holes allow anchor to floor. Rust and acid resistant safety yellow powder coat finish for long lasting durability. Feature adjustable chains for securing vertical cylinders, adjust in 1" increments. Vertical storage lockers accept all standard vertical cylinders up to 59¾" or 65". Horizontal cylinder storage lockers accommodate 20 and 33½" lb. LPG cylinders and canisters. Warning " DANGER FLAMMABLE MATERIALS " sign located in front of the doors. Easy Assembly with pre – drilled holes on frame. The steel Cylinder storage cabinet locker meet all relevant NFPA and OSHA standards for storing dangerous and flammable materials such as compressed gas/air cylinders and containers with ventilation and visibility.



Specification

Cylinder Cabinet Storage Type Vertical
Cylinder Capacity 9 Cylinder
Cylinder Size 20 lb. & 33 lb
Cylinder type LPG
Height 65 Inch
Width 31 Inch
Depth 30 Inch
Safety Cabinet Door Type Manual with Magnetic
Number of Adjustable Cabinet Shelves 0
Number of Fixed Cabinet Shelves 1
Total Shelf Quantity 1
Door Quantity 1
Number of chain 1
Assembled/Unassembled Unassembled / Predrilled Holes for Mounting
Color Yellow
Safety Cabinet Standards OSHA 1910, NFPA 30
Rated For Flammable Storage Yes
Roof Material 14 ga. Steel
Construction Expanded Metal, Angle Iron Frame
Finish Powder Coated
Weight 166 Pounds
